RF Cable Assemblies for Space-System Development and Test
Phase-stable RF cable assemblies for satellite payload testing, integration facilities and ground equipment. Flight and thermal-vacuum requirements are reviewed against the specific application.
Interconnect Selection for Space-System Testing
Space-system development depends on repeatable RF measurements during component characterisation, payload integration and ground testing.
RadianWorks supports interconnect selection based on frequency, attenuation, phase stability and mechanical routing. Applications involving vacuum, outgassing, radiation, launch loads or flight installation require specific material and qualification review.
Typical Applications
Payload Integration and Test
RF assemblies for payload integration facilities and performance verification.
Satellite Component Characterisation
Interconnects for laboratory measurements of RF components and subsystems.
Ground-Station Equipment
Assemblies for ground-equipment development, integration and testing.
Ground-Based TT&C Development
RF interconnects for telemetry, tracking and command equipment development and test.
Environmental-Test Interfaces
Assembly requirements for test-chamber connections are reviewed against temperature, pressure, sealing and material constraints.
Engineering Challenges
Measurement Stability
Define allowable cable-induced phase and amplitude changes during the test sequence.
Mechanical Handling
Review routing, movement and repeated-bending requirements during integration and test.
Environmental Conditions
Identify temperature, vacuum and material requirements rather than assuming suitability from general cable ratings.
Connector Interfaces
Select interfaces against frequency, equipment compatibility and installation access.
Documentation
Agree applicable traceability, acceptance-test and qualification documentation before order placement.
Recommended Products
FX18
18 GHzStranded-conductor RF cable assemblies for applications requiring flexibility up to 18 GHz.
View Product
FX26
26.5 GHzFlexible RF cable assemblies to 26.5 GHz, with an 18 mm static and 50 mm repeated bend radius.
View ProductCompleted assembly frequency depends on the selected cable and connector interfaces. Refer to the product datasheet for configuration limits.
Assembly Configuration and Engineering Support
Define Your Assembly Requirements
Assembly requirements can be reviewed against customer drawings or an application specification.
- Customer drawings and specifications
- Assembly lengths and connector interfaces
- Phase-matching requirements
- Mechanical protection and strain relief
- Identification and labelling
- Agreed test and documentation requirements
Discuss Your Space-System Test Requirements
Provide your operating frequency, connector interfaces, routing constraints and environmental requirements. Our engineering team will review the assembly options for your application.
